| Ducting |
optional accessory |
| Top or rear duct hole |
top |
| Recirculation option |
Yes |
| Recirculation kit |
optional accessory |
| Front recirculating option |
No |
| Type of filter |
Charcoal |
| Filter |
Optional |
| Number of optional filters required |
two |
| Ducting diameter (mm) |
150 |
| Cut out depth (mm) |
262 |
| Cut out width (mm) |
833 |
| Total product height (mm) |
249 |
| Total product width (mm) |
866 |
| Total product depth (mm) |
292 |
| Diameter of ducting (mm) |
150 |
| Minimum installation height from cooking surface Gas (mm) |
620 |
| Minimum installation height from cooking surface Electric (mm) |
600 |
| Control panel |
push button |
| Safety/ display indicators |
auto thermal cutout safety switch |
| Hob2Hood function |
No |
| Number of filters |
3 |
| Type of filter |
multilayer aluminum micromesh filters |
| Number of lights |
2 |
| Wattage of light |
3.5 |
| Type of light |
LED |
| Noise level dB low |
54 |
| Number of fans |
1 |
| Number of fans speeds |
3 |
| Type of motor |
tangential |
| Perimeter extraction |
No |
| Maximum airflow M3/Hr |
680 |
| Noise level dB high |
68 |
| Number of motors |
1 |
| Wattage of motor |
235 |
| Type of Rangehood |
integrated under cupboard |
| Nominal width (cm) |
86 |
| Finish of Rangehood |
stainless steel |
| Domestic warranty details (yrs) |
2 |
