| Type of light |
LED |
| Number of lights |
2 |
| Wattage of light |
5.5 |
| Cut out depth (mm) |
276 |
| Cut out height (mm) |
200 |
| Cut out width (mm) |
455 |
| Total product height (mm) |
200 |
| Total product width (mm) |
512 |
| Total product depth (mm) |
304 |
| Diameter of ducting (mm) |
120 |
| Minimum installation height from cooking surface Gas (mm) |
650 |
| Minimum installation height from cooking surface Electric (mm) |
600 |
| Control panel |
slide switch control |
| Safety/ display indicators |
auto thermal cutout safety switch |
| Hob2Hood function |
No |
| Number of filters |
1 |
| Type of filter |
multilayer aluminum micromesh filters |
| Ducting |
optional accessory |
| Top or rear duct hole |
top |
| Recirculation option |
Yes |
| Recirculation kit |
optional accessory |
| Front recirculating option |
No |
| Type of filter |
Carbon |
| Filter |
Optional |
| Number of optional filters required |
two |
| Ducting diameter (mm) |
120 |
| Noise level dB low |
49 |
| Number of fans |
1 |
| Number of fans speeds |
2 |
| Type of motor |
single motor |
| Perimeter extraction |
No |
| Maximum airflow M3/Hr |
340 |
| Noise level dB high |
67 |
| Number of motors |
1 |
| Wattage of motor |
100 |
| Type of Rangehood |
integrated under cupboard |
| Nominal width (cm) |
510 |
| Finish of Rangehood |
stainless steel |
| Domestic warranty details (yrs) |
2 |
