Description
Miele 80.6cm Gas Cooktop KM 3034-1
Gas cooktop with electronic functions for maximum safety and user convenience.
- Optimal – single-handed operation via rotary dials and QuickStart
- Elegant design – 80.6cm wide gas on glass cooktop
- Particularly versatile – 3 burners incl. 1 dual wok burner
- Extremely safe – GasStop&Restart function
- Easy cleaning – dishwasher-safe ComfortClean pot rests
Wok burner
Perfect wok kitchen with gas cooktops
Gas cooktops and wok cooking - they simply belong together. Miele offers two varieties of wok burners: The Mono wok burner with integrated power regulation for both flame rings. And the Dual wok burner, on which the two flame rings can be regulated separately.
ComfortClean pot rests
Efficiently protects and makes cleaning easier
Miele gas cooktops are equipped with pot rests which can be cleaned in the dishwasher. This makes cleaning the Miele gas cooktop and the continued use of the appliance particularly easy and saves time.
GasStop
Flame failure monitor for maximum safety
All Miele gas cooktops are equipped with thermo-electric flame failure monitors. If the gas flame is temporarily extinguished, e.g. because a pan boils over or due to a draught, a flame failure device will stop the supply of gas.
Front knob controls
Everything under control
Miele gas cooktops are operated by plastic or metal controls. Power can be adjusted particularly easily and safely.
Electronic ignition and single-handed controls
Comfortably reignite the flame
Automatic ignition of burners thanks to intelligent technology. Simply turning the dials during the ignition process with just one hand is easy to do.
Enamelled pot rests and burner parts
High quality features for a long life
Miele gas cooktops are equipped with enamelled cast iron pot rests - robust and durable, a visible sign of first-class quality. In addition, some gas cooktops are equipped with PerfectClean burner heads, making cleaning easier thanks to the non-stick coating.
Specifications
Technical Data
| Dimensions (W x D) in mm | 806 x 53 x 526 |
| Dimensions in mm (width) | 806 |
| Dimensions in mm (height) | 78 |
| Cut-out dimensions (W x D) with surface-mounted installation in mm | 780 x 500 |
| Dimensions in mm (depth) | 526 |
| Weight in kg | 20 |
| Total rated load in kW | 11.65 |
| Voltage in V | 230 |
| Frequency in Hz | 50-60 |
| Length of supply lead in m | 2 |
Cooking zone details
| Cooking Zone | Position | Type |
| 1st | front left | high speed burner |
| 2nd | rear left | economy burner |
| 3rd | centred | dual wok burner |
| 4th | rear right | standard burner |
| 5th | front right | standard burner |
User convenience
| Operation via dials | Yes |
| Electronic ignition - single hand operation | Yes |
| Display colour | Red |
| QuickStart | Yes |
Construction and design
| Heating type | Gas |
| Independent of cooker | Yes |
| Elegant glass ceramic surface | Yes |
| Ceramic surface colour | Black |
| Cast-iron pot rests (matt black enamelled) | Yes |
Safety
| Heat indicator | Yes |
| Operational indicator | Yes |
| GasStop & ReStart | Yes |
